Mini 3G SDI to HDMI Converter
৳ 5,000
৳ 5,500
* বর্তমানে আইটি পণ্যের দাম স্থিতিশীল না থাকায়, ওয়েবসাইটে দেয়া পণ্যের মূল্য বাড়তে পারে। *
How To Order: Over Phone, Email or Checkout in website. We Will Contact You Soon.
Description
Mini 3G SDI to HDMI Converter with Audio –
SD/HD/3G-SDI to HDMI Adapter for Video & Embedded Audio Output
The
MINI SDI to HDMI converter allows SD-SDI, HD-SDI and 3G-SDI signals to be
shown on HDMI displays while ensuring high bit rates of 2.970 Gbit/s to give
you fast signal transmission without any loss. For professionals this means
that it is now easier to distribute and extend your 3G SDI signal while giving
you the ability to display your work on HDMI displays thanks to the built in
HDMI converter.
Key Features:
-
Supports multiple data rates: 2.970 Gbit/s, 1.485 Gbit/s, and 270 Mbit/s
-
Fully compatible with SMPTE standards: 425M, 424M, 292M, 259M-C
-
Integrated audio de-embedding for up to 8 channels at 48KHz
-
Built-in equalizer and re-clocker for improved signal stability
-
Converts SMPTE 425M Level B to Level A (1080p 50/59.94/60, 4:2:2, 10-bit)
-
Daisy-chain capable – connect multiple units to extend signal transmission over long distances
Ports & Controls:
-
SDI IN – Connect your SDI source here
-
HDMI OUT – Outputs the converted HDMI signal
-
POWER LED – Red light indicates device is powered on
-
DC IN – Accepts 5V to 12V power input
Package Includes:
-
3G SDI to HDMI Converter – 1 PC
-
5V DC Power Supply Adapter – 1 PC
-
Operation Manual – 1 PC
Technical
Specification
|
Specification |
Details |
|
Input
Port |
1
x BNC (SDI/HD-SDI/3G-SDI) |
|
Output
Port |
1
x HDMI |
|
SDI
Transmission Rates |
2.970
Gbit/s and 2.970/1.001 Gbit/s |
|
In/Output
Resolution |
480i,
576i, 720p@50/59.94/60, 1080i@50/59.94/60 |
|
1080p@23.97/24/25/29.97/30/50/59.94/60 |
|
|
Power
Supply |
DC
5V - 12V |
|
ESD
Protection (Human body) |
±8kV
(air-gap discharge), ±4kV (contact discharge) |
|
Dimension |
80mm
x 41mm x 25mm |
|
Weight |
150g |
|
Operating
Temperature |
0°C
~ 40°C / 32°F ~ 104°F |
|
Storage
Temperature |
-20°C
~ 60°C / -4°F ~ 140°F |
|
Relative
Humidity |
20%
~ 90% RH (Non-condensing) |
|
Power
Consumption (Max) |
5W |
